While working on my latest commission, I had to find out how to make lava for the model’s base.
I already did several lava bases. So in order to avoid boredom I had to come up with a new idea or end up with boring and uninspired results.
So I returned to browsing the internet for photos of lava:
Now this is something I haven’t done before! 😀
What we need to make lava
How to make lava that is boiling and splashing? We will need:
sheet of plastic (I used a thick plastic sleeve)
source of heat (I used a candle)
filler putty (I used a modeling putty for plastic models)
Vallejo Water Effect
hygroscopic balls (you will find them in a new wallet or handbag, where they’re supposed to absorb moisture)
airbrush (you can do without it, but I used mine)
paints: white, black, Vallejo MC 952 Lemon Yellow, Vallejo Ink Skin Wash, Winsor & Newton Orange Ink, Vallejo MA Mahogany, Reaper Red Brick 09001, and saturated red of your choice.
retarder (because regular Vallejo paints tend to clog my airbrush)
So how to make lava like that?
I pulled, stretched and bent stripes of plastic over fire:
I made a test application of the lava surface on a sheet of metal. The consistence of my putty made it a suitable material to imitate lava:
I ruffled the fresh putty with a toothpick and added the splashes I formed from plastic:
When the putty was dry, I finished the rest of my lava base with Vallejo Water Effect. Its thickness is similar to that of mayonaise, so it feels perfect for the task. If you want to make finer splashes of lava than mine, you can apply some water effect on a piece of thin wire:
I left the base to dry overnight and in the morning I started with priming the base. Then I used my airbrush to apply several layers of paint to build up colors of lava:
I checked if it fits to the scenic base:
I could see I was going in the right direction. Now I only needed more contrast, so I returned to painting.
I highlighted the hottest parts once more with Vallejo MC 952 Lemon Yellow. Once more I applied Winsor&Newton Orange to increase saturation. I glazed some parts with my red. And then with the side of a paintbrush I painted cooled cracks with Reaper Red Brick 09001 and black:
Finished lava base
Finishing touches were done later, when the model for which the base was made was ready. Now you should know how to make lava splashes for your minis and see the finished thing here:
I hope this tutorial was helpful to you. If you have any hints or tips, feel free to let me know about them or discuss this technique in the comments below.
For priming I used a combination of black and white primer.
Generally I use a basecoat color, 3-4 shadows and 3-4 highlights for one part/detail. So I end up with a total of 7-9 colors which I use to create the transition from the deepest shadow to the brightest highlight.
Paint mixing ratios
All my paint ratios in this Mad Hatter tutorial represent my drop count (I have all my GW paints refilled in empty Vallejo-like dropper bottles which makes it easier for me when mixing colors) – for example:
GW Tallarn Flesh : VMC Dark Flesh #019 (3:1)3 drops GW Tallarn Flesh : 1 drop VMC Dark Flesh #019GW = Games Workshop / Citadel
VMC = Vallejo Model Colour
Dilution of my paints is about 50% paint to 50% water for glazing (highlights and shadows) and my basecoat is a little bit thicker so about 70% paint to 30% water.
Ok, let’s get started with painting the Malifaux Seamus the Mad Hatter miniature. 🙂
1. Face, eyes and skin:
It’s good for all the readers of my Seamus the Mad Hatter tutorial to know that I always start with the head/face of a mini and then move to the next part. I only paint one part at a time and pretty much finish it before I move to the next one. For the skin I used GW Tallarn Flesh as a basecoat color and applied 2-3 thin layers until I had nice even coverage.
Basecoat:GW Tallarn Flesh
[inset side=right]I always start with the head/face of a mini and then move to the next part. I only paint one part at a time and pretty much finish it before I move to the next one.[/inset]
After the skin was basecoated I painted the eyes:
First I painted the eye-socket white.
Next I thinned down some VMC Black #169 (about 20% paint : 80% water) and used it to outline the eye-socket by letting the paint flow into the recesses by itself.
Usually I mess up the white eye-socket a bit or my outline will end up being to intense/thick. Therefore I carefully repaint the eye-socket white and correct the black outline a bit.
Next I painted black dots for the pupils with a less diluted paint (70-80% paint : 30-20% water).
Once the eyes were done I switched back to his skin and started with the shadows.
I applied the first shadow always moving the brush towards the deepest parts which will later receive the darkest color and using many layers always leaving a bit of the previous brush stroke untouched to build up the first shadow. Then I applied the second and third shadow also leaving a bit of the previous shadow untouched to build a transition towards the darkest shadow. Colors I used for the shadows:
Shadow I:GW Tallarn Flesh : GW Scorched Brown (6:1)
Shadow II:GW Tallarn Flesh : GW Scorched Brown (3:1)
Shadow III:GW Tallarn Flesh : GW Scorched Brown (1:1)
The last shadow color (Shadow IV) was used for the deepest recesses like his mouth and facial wrinkles.
Shadow IV:GW Scorched Brown
Then I started painting highlights. It’s pretty much the same as with shadows – moving the brush towards the highest parts which will receive most of the light, always leaving a bit of the previous highlight untouched to build a transition from the basecoat to my last highlight. The method presented here, in this Mad Hatter tutorial, is the one I usually use. Colors used for the highlights:
Highlight I:GW Tallarn Flesh : VMC Dark Flesh #019 (3:1)
Highlight II:GW Tallarn Flesh : VMC Dark Flesh #019 (1:1)
Highlight III:GW Tallarn Flesh : VMC Dark Flesh #019 : GW Skull White (1:1:2)
I used the last highlight (Highlight IV) only for a few bright-spots.
Highlight IV:GW Tallarn Flesh : VMC Dark Flesh #019 : GW Skull White (1:1:4)
I basecoated his hair with the following mix:
Basecoat:GW Shadow Grey : VMC Black #169 (2:1)
Then highlighted it getting brighter towards the outside with the following colors:
Highlight I:GW Codex Grey (1:1 water)
Highlight II:GW Codex Grey : GW Skull White (2:1:3 water)
3. Coat, tuxedo and hat
I did some preshading and highlighting here that’s not something I usually do it sometimes just happens. 😉
After this was done I messed around with mix-ratios until I was satisfied with the colors and came out with the following mixes:
Highlight IV:GW Enchanted Blue : GW Hawk Turquoise : GW Space Wolves Grey (2:1:9) + some GW Skull White
Highlight III:GW Enchanted Blue : GW Hawk Turquoise : GW Space Wolves Grey (2:1:9)
Highlight II:GW Enchanted Blue : GW Hawk Turquoise : GW Space Wolves Grey (2:1:6)
Highlight I:GW Enchanted Blue : GW Hawk Turquoise : GW Space Wolves Grey (2:1:3)
Basecoat:GW Enchanted Blue : GW Hawk Turquoise (2:1)
Shadow I:GW Enchanted Blue : GW Hawk Turquoise : VMC Black #169 (2:1:1)
Shadow II:GW Enchanted Blue : GW Hawk Turquoise : VMC Black #169 (2:1:2)
Shadow III:GW Enchanted Blue : GW Hawk Turquoise : VMC Black #169 (2:1:3)
I painted highlights and shadows like described in the face part always moving the brush towards the deepest shadows and brightest highlights, using many thin layers and slowly building up the color.
The last highlight (Highlight IV) was only used on the upper parts as a last “popping” highlight like on the folds on his arm or his collar.
4. Belt-thing on his hat
Highlight III:GW Bestial Brown : GW Bleached Bone (2:3)
Highlight II:GW Bestial Brown : GW Bleached Bone (2:2)
Highlight I:GW Bestial Brown : GW Bleached Bone (2:1)
Basecoat:GW Bestial Brown
Shadow I:GW Bestial Brown : VMC Black #169 (3:1)
Shadow II:GW Bestial Brown : VMC Black #169 (3:2)
I paint every part as described above (first I apply the basecoat with 2-3 layers and then paint the shadows and highlights) so for the next few parts of my Mad Hatter tutorial I will only post the colors I used. 🙂
Basecoat:GW Bestial Brown : GW Graveyard Earth (2:1)
Shadow I:GW Bestial Brown : GW Graveyard Earth : GW Scorched Brown (2:1:1)
Shadow II:GW Bestial Brown : GW Graveyard Earth : GW Scorched Brown (2:1:2)
Shadow III:GW Bestial Brown : GW Graveyard Earth : GW Scorched Brown (2:1:3)
6. Weapon – wood
Basecoat:GW Bestial Brown : VMC Dark Flesh (2:1)
Shadow I:GW Bestial Brown : VMC Dark Flesh : GW Scorched Brown (2:1:1)
Shadow II:GW Bestial Brown : VMC Dark Flesh : GW Scorched Brown (2:1:2)
Shadow III:GW Bestial Brown : VMC Dark Flesh : GW Scorched Brown (2:1:3)
Some of you may be checking this Mad Hatter tutorial in search for my NMM recipe. When I painted the NMM parts like his blade I tried to to push the highlights up to pure white and the shadows to a dark almost black tone. The colors I used for the silver NMM parts were:
Highlight IV:GW Skull White (pure)
Highlight III:GW Codex Grey : GW Skull White (1:3)
Highlight II:GW Codex Grey : GW Skull White (1:2)
Highlight I:GW Codex Grey : GW Skull White (1:1)
Basecoat:GW Codex Grey
Shadow I:GW Codex Grey + VMC Black #169 (3:1)
Shadow II:GW Codex Grey + VMC Black #169 (2:1)
Shadow III:GW Codex Grey + VMC Black #169 (2:2)
Shadow IV:GW Codex Grey + VMC Black #169 (2:3)
To increase the last shadow a bit on the silver NMM parts I used some very diluted black (like a wash it was mostly “black water”) and carefully glazed this mix at the very end (bottom) of the last shadow.
All Gold NMM parts were painted with the following colors:
Highlight III:GW Skull White (pure)
Highlight II:GW Snakebite Leather : GW Bubonic Brown : GW Skull White (1:1:3)
Highlight I:GW Snakebite Leather : GW Bubonic Brown : GW Skull White (1:1:1)
Basecoat:GW Snakebite Leather : GW Bubonic Brown (1:1)
Shadow I:GW Snakebite Leather : GW Bubonic Brown : GW Scorched Brown (1:1:1)
Shadow II:GW Snakebite Leather : GW Bubonic Brown : GW Scorched Brown (1:1:2)
Shadow III:GW Scorched Brown (pure)
Shadow IV:GW Scorched Brown : VMC Black #169 (2:1)
When painting small details like the gold NMM stuff on his bag or the belt buckle on his hat I usually don’t use the complete range of mixes. I basecoat the area as usual, use the first shadow/highlight but then I leave the second mix out and jump to the third shadow/highlight.
For large surfaces it’s the same procedure as with the other parts.
8. Bag & accessories
The NMM parts were painted with the colors described above in an earlier part of this Mad Hatter tutorial and for the bag I used the following mixes:
Glaze:VMC Yellow Ochre #121 (80% water) — only glazed over the highlights to get a bit of a yellow in there
Highlight III:GW Bestial Brown : GW Bleached Bone (2:3)
Highlight II:GW Bestial Brown : GW Bleached Bone (2:2)
Highlight I:GW Bestial Brown : GW Bleached Bone (2:1)
Basecoat:GW Bestial Brown
Shadow I:GW Bestial Brown : GW Scorched Brown (2:1)
Shadow II:GW Bestial Brown : GW Scorched Brown (2:2)
Shadow III:GW Bestial Brown : GW Scorched Brown (2:3)
Ok that’s pretty much it. I hope you enjoyed reading this little walkthrough and found something interesting.
And here are some final pictures of the miniature. If you recreated the steps presented in my Seamus the Mad Hatter tutorial, you should achieve similar results:
Following Mahon‘s suggestion I decided to write my first miniature painting tutorial on Chest of Colors website. It is a tutorial about painting NMM gold my way – fast and pleasant.
Contrast is the most important thing in NMM technique.
This technique is intended for using mainly on tabletop quality figures, but with more layers (I used just 7-8 here, including base color and a wash) it can look quite well even on display miniatures.
I will show my technique on terminator librarian shoulder pad. It is hard for me to give precise proportions, as I use mostly my intuition while mixing the colors.
NMM gold – JerzyK’s way
I start with base color (pic. 1) by mixing yellow with little brown and blue, ending in dirty yellow – it is just the way it should be 😉
Then I make wash color by adding more brown to the mix and diluting it to dirty water consistency and apply it to the surface (pic. 2) – it helps to mark various hollows on the surface, which are afterwards emphasized with more precise application of another layer, which is basically wash color with addition of a little black.
The next step is cleaning everyting a little bit with basic color (pic. 3) – washes can sometimes leave messy areas.
I add a little white and blue to the basic color and focus on areas which would collect more light (pic. 4).
From this step I will be creating more and more contrast, which is the most important thing in NMM technique. Another layer of lighter color (more white and blue) is applied within the limits of the first highlight (pic. 5).
Finaly I use almost white highlight with pure white blicks on highest places (pic. 6).
Sometimes before the last step (white and almost-white highlights) I apply blue or green strongly diluted layer if overall color is too yellow.
You can easily evolve my techniqe to get better results, but even now with just a few layers and little time you can achieve effect which look well on gaming miniatures (pic. 7).
And here is another example of a miniature painted in a similar way:
What would you say if I told you all of the horses in the photo below were painted with dry pigments. No, I don’t mean add a medium to turn the dry pigment into oil or acrylic paint. I mean honest to goodness application of dry pigments. If you want to learn how to paint with dry pigments, read on.
You probably think I’m nuts or the technique would be more trouble than it’s worth – or that it would wipe out detail. You could probably come up with lots of reasons not to try it.
But here you are reading this article. 😀
While I paint miniatures and various historical figures, I also paint model horses. This is a huge hobby but very few people know about it. It is very similar to the miniatures hobby, the only thing different is the focus of the subject – to create the most realistic and accurate to real life horse as possible.
It was in the model horse hobby that I learned this technique and I’d like to share it with you.
How to paint with dry pigments: Principle
The general idea is very simple. Pigments and pastels are translucent tints – meaning they are not completely opaque. You build from light to dark and slowly work toward the color you want to achieve. The top layer’s color is affected by all the layers below it.
Pigments and pastels are translucent tints – meaning they are not completely opaque. You build from light to dark and slowly work toward the color you want to achieve.Starting with a white base, you select a light color and literally stain your subject with a brush or applicator and slight pressure. When you have colored the desired surface, you seal the pigment or pastel with matte sealer. Once the sealer dries, you do it all over again. The color you end up with simply depends on where you stop.
Lighter colors, of course, take less layers. Darker colors, all the way to a rich black with blue and brown undertones can take several. Pigments are pure color, they have no binder so typically take less layers than pastels. While I use both depending on the effect I want, I prefer pigments because of the richer color and better coverage.
Before we begin, allow me to list what you may need, or a least need to know about.
I use both pigments and pastels depending on the desired effect I want to achieve. For pastels you need to purchase a high quality brand. Pastels are colored pigment and a binder, so they keep their stick shape. The binder does not have any color. The cheaper pastels have more binder and less pigment, therefore it takes more to achieve a desired color. The higher quality brand names such as Rembrandt, Sennlier, Unison, etc. have more pigments and less binders, so these are the ones you should focus on.
I use exclusively Earth Pigments. There are several companies that make pigments, including many for the miniature world for use in weathering. There are also pigments sold by art supply retailers such as Dick Blick that sell powdered pigments made for the oil painter to make their own oil paints. I would like to caution the reader about these. Please check the labels! The pigments for oil paints can contain ingredients that are toxic – cadmium for Cadmium Blue for example, is toxic. If you have children and/or pets, be aware that pigment dust will get EVERYWHERE. There is really no way to control it no matter how careful you are. So know what is in your supplies.
I use Earth Pigments because they have high quality colors, they have a UV rating, their jars are inexpensive and for what we are doing this small amount will literally last years, and best of all they are NON-TOXIC. Yay! Now, they do have a warning not to breathe in the dust, so it’s a good idea to have a mask, especially if you’re sensitive to things like this. But as a whole, Earth Pigments have a lot of fantastic things going for them.
For those of you in Europe, I have a link (I need to dig it up) for a company that is sorta like Earth Pigments “sister” site, where you can get the same thing. I believe they are in France.
Like regular pastels, pan pastels are pigment mixed with a binder. But these are pressed into a small pan – very much like a make up compact – so the binders are far less than regular stick pastels. They have fantastic color and go on smooth. Once again they are easily available and not that expensive. I like using the Grays Set of 5 from Dick Blick. But they come in a huge variety of colors, tints and shades, so if you want to get others, go right ahead! These little pans actually screw together to form a stack, so everything stays neat and tidy and they are easy to store.
Pearl Ex metallic pigments
Not required for the first couple of projects but trust me, if you don’t get them you’ll soon wish you had. These are fantastic for armor and for horses you add just a touch to get the nice sheen of a healthy coat. I have the Series 1 12 Color Set with Free Book except for the neon violet color, all of the other colors work perfectly for armor, metal items, and natural horse colors. But honestly, if I had the money to get all 32 colors, I would! With these comes one caveat….
if you get the Pearl Ex metallic pigments you really need to get the colour shapers. While I want to demonstrate and explain the products I use, I don’t want to say YOU MUST BUY THIS. But these two items go hand in hand and my experience with the generic brands has been poor, so these are the ones I strongly encourage you to get.
I tried applying with a brush and POOF glittery dust explosion everywhere! I tried mixing them with the pigment powder but it was either ineffective or I still had glittery dust everywhere.When I first started using the Pearl Ex, I did not have these and I absolutely hated the pigment. I tried applying with a brush and POOF glittery dust explosion everywhere! I tried mixing them with the pigment powder but it was either ineffective or I still had glittery dust everywhere. These things were so hard to control and to apply where I wanted that I just about threw them in the trash. I’m glad I didn’t.
Out of sheer luck I found the Colour Shapers on Dick Blick and decided to try them. They worked nicely, they are a non-porous rubber so you can use them for paint or glue and just wipe them off afterward. Stuff doesn’t stick to them. In desperation, I tried them to apply the Pearl Ex. It worked like a charm! Now I have almost complete control of application and can apply them onto even the smallest piece of armor. Or I can apply metallic pigment to a large muscle on the horse to get that realistic sheen and not worry about it flying into areas where I don’t need it.
Colour Shapers just came out with a Mini Set that is perfect for our jobs. I purchased the Firm set then went back and purchased the extra firm set (Clay Shapers). I use them both depending on the job at hand. Whichever one you get depends on your style but you will really love these when it comes time to apply the metallics. Trust me on this one! You’re gonna want the Mini set Size 0.
Another must have. You will need white at the very least. I prep my horses then apply gray primer because the contrast on the larger scale helps me see anything I missed. (When working on miniatures, I only use white because I don’t want the added layers.) Then I cover the model in white primer.
My favorite brand is Tamiya Fine Surface Primer, both white and gray but at the time of this writing, Tamiya aerosol cans of any sort are not allowed in the U.S. Due to labeling issues. My second choice (and it’s not far behind Tamiya in quality), Is Vallejo White and Vallejo Gray aerosol primers, in fact, I may stick with it even if Tamiya comes back. I tested it first and while it’s a bit too easy to over apply and get it to run, it applies nicely and does not cover fine detail.
Basically you want a high quality white primer that has enough “tooth” for the pigments to stick to but not too much or there will be difficulties with grain down the road. No matter what brand, you MUST prime white as the last step. In order to properly apply pigments and pastels, you must have a white base coat to start.
I use Testors Dull Cote because it is very matte and is non-yellowing. Plus, it provides the right amount of tooth. If your preference is more towards glossy figures, you can use gloss sealer but be aware gloss has less tooth and it will be more difficult to apply the pigment.
The sealer I use is Testors Dull Cote. It’s an acrylic lacquer I believe. Many figure and mini painters use it, especially if they game with their minis. I know folks who don’t game are moving away from sealer because there is too great of a chance of that sealer doing strange things and ruining their hard work. This is why I always spray a test model first, no matter how many times I’ve used that can of sealer.
Certain sealers can react with the primer even if you have several layers in between.I use the same sealer for all of it, paint, pigment, pastels. The type of sealer you use is entirely up to you and if you have a brand preference. But also be aware that certain sealers can react with the primer even if you have several layers in between. That happened to a friend of mine. She started using Tamiya primer, painted a horse using the exact same technique I just described, but when she applied Krylon clear sealer, it started to bubble and everything down to the primer just flaked off. We ended up contacting Tamiya USA and while they had never heard of this happening before, they said it sounded like the Krylon sealer and their primer were not compatible. Anyway, she went back to Testors and everything has been just fine ever since.
I even use the Dull Cote on the metallics. Yes, it dulls them down just a little but I can usually get three layers of spraying Dull Cote on the mini before it dulls the metallics completely.
For applying pigments and pastels you do NOT want to use your good paint brushes. Now is the time for the cheap nylon that can stand up to anything you throw at them. Applying this stuff is hard on brushes and you need the kind that is not too soft or you will hit the brush ferrule against the mini. So get the white nylon brushes that are on sale at Walmart or Michaels for next to nothing. The assorted shapes such as the filbert, flat shader and angled shader also come in handy.
The stackable type come in very handy for mixing pigments and using with pastel sticks. If you take a jar and a pastel stick, hold the stick over the jar and drag the stick against the edge moving inside out, it will grind the stick into powder and the powder just falls right into the jar….for the most part.
Various grits (180 to as high as you can find them) sanding sponges. Do not use sandpaper! Pointed cotton swabs from the make up aisle at Walmart or Walgreens, etc. the cheapies are just as important as the expensive ones, Tamiya pointed cotton swabs, Canned Air – the same stuff you use for electronics. Colored Pencils – such as Derwent (not water color), Black Charcoal Pencil, White Charcoal Pencil, Brush on Gloss, Gesso (or white brush-on primer), and a Carbide Scraper are all very handy. Don’t put your acrylics and brushes away just yet! You’ll still need those.
Painting: How to apply dry pigments and pastels
I have a Work In Progress thread going on CMON and I used a knight’s cloak as an example of how to apply dry pigments. So I’m going to draw on those photos for the purposes of this article. The character in question is Pegaso‘s Roaming Knight and I had started painting the cloak with acrylics, then decided to apply pigments instead and used the example of why we must start with a white base when using pigments and pastels.
So, our knight is starting of with a standard acrylic layer of paint, a sort of olive drab – think of the old army blankets. It’s nothing special, I had wet-blended the acrylic and finished the first layer. Then I decided to switch to pigments.
It is important to understand that pastels and pigments are tints. They are translucent and the first color will show through the second color. The two combine to give you a shade. Start with white primer (or white paint) as a base. It is also important to work from light to dark. So the next step was deciding on the color of pigments I wanted to use.
Note: Because of my hand tremors and the way I need to work, I’m only going to be working on one side of the cloak at a time since I have to lay the model down to work on it. As you can see, I layer towels and do all I can to protect the work I’ve already done.
I haven’t used this color at all because it has a strong green undertone and is quite inappropriate for horses. So here it sits, waiting. Now was a perfect opportunity to try it out. I purchased these several years ago, before Earth Pigments had accurate photos up, so the strong green undertone didn’t come through until it arrived and I opened the jar.
This is another strong green undertone color that I haven’t had the chance to use.
A friend sent this to me to try. This is a relatively new color in the Earth Pigment line. There is another black, an Oxide pigment, Black 318 that is very strong and very intense. It is so strong, it can wipe out almost anything and everything else. Natural Black is softer, and the blue undertone is supposed to be less.
So these are the colors I decided to start with and I’m prepared to adjust as I go. Applying pigments and the color achieved is not an exact science. No matter how often I work with them, they can still surprise me and do so quite often.
Why you need a white base
In order to demonstrate the need for a white base, I start by applying the Light Sienna directly to the knight’s green acrylic painted cloak. I’m not shy about it either. I put my brush into the pigment and load it up. Then I tap off the excess on the side of the jar – otherwise you will have a cloud of dust that won’t quit. I firmly press the brush against the cloak but not so hard that I push the ferrule into it. I use a slight stippling motion with a drag to apply the pigments. I’m literally staining the cloak as I go.
In order to get really solid coverage of pigment. I get my Colour Shaper out and use that to press the pigment onto the cloak. When it’s finally covered, I take my canned air and blow off the excess dust. This is an important step. If the excess powder remains, and sealer is applied, it literally turns to mud. Now if we were truly weathering, we might want this effect but for this, we don’t.
You can also use lung power to blow of the dust but I guarantee if you do, sooner or later you’re going to spit on your work. Trust me, it’s happened to me more times than I care to count and it will happen to you eventually. When that happens, set the model aside to dry. If you don’t mess with it, it should disappear on its own.You can also use lung power to blow of the dust but I guarantee if you do, sooner or later you’re going to spit on your work.
Once the excess dust is blown off it is time to seal. Take the Dull Cote and be sure to shake well! In fact, it’s a good idea to have a test model handy because cans have been known to freak out and do crazy things in the middle of spraying. So hitting a test model first is better than ruining your hard work.
You want to lightly cover the area with pigment. Do not soak it, do not let it puddle. In fact, 2-4 very light coats of sealer is the way to go. It also depends on the size of the model, a large one will need more than a small one. The really small ones you need to be very careful of how many layers and how thick you apply so you don’t obscure fine detail.
Now our sealer is applied and what do we have to show for it?
A big mess! The pigments actually disappeared against the dark base coat. The only thing that remains are the yucky spots where I applied too much pigment and too much sealer. I’ve circled the problem areas in the photo and did this to make a couple of important points. If you do not use a white base, your pigments will most likely disappear. You will also probably attempt to apply them too thick and end up with mud as in the photo.
The above photo looks absolutely atrocious.
But I also want to point something out. Even though our pigment disappeared agains the dark base, if you look closely where I have the blue arrows, you can see where some of it did highlight an area or two. The effect is very subtle and difficult to see, but it is there.
So now what do we do? Is our knight hopeless because I applied pigment to a dark basecoat? Do I have to strip him?
No – he is still very manageable. With a little effort he will be right as rain.
The first thing I do is use a high grit sanding sponge – a sponge, not sandpaper to lightly sand off the pigment mud and goobers left behind. Sandpaper will crease and gouge the layers, many times damaging your basecoat.
I don’t even have to strip the cloak, just get the nasties off. Once I do that, I take Gesso and thin it really well. Gesso is infamous for leaving brush strokes so you want it good and thin. If you don’t have Gesso, in this particular case – recovering from a mistake – brush on primer will work just as well. I recently purchased Vallejo’s White Brush-On Primer and I love that stuff! Gesso is out the door unless I’m out of the Vallejo.
I apply two layers of Gesso to the cloak. Now we have our white basecoat and can move forward.
Remember always apply colors light to dark. You need to work in layers. Trying to rush to a darker color will only lead to problems. You are basically working with colored dirt here. Ochers and Oxide pigments are like little grains of sand. They don’t dissolve. You press them into your base until there is no more surface area for the grains to adhere to. Once the layer has reached its “saturation level” the pigment color will stop growing darker or denser. That means it’s time to seal.
<span=”inset-right”>Once the layer has reached its “saturation level” the pigment color will stop growing darker or denserApplying sealer keeps the tiny pigment grains in place. It also provides a new, relatively clean surface area for more grit to adhere to so you can apply another layer. But rushing this and going dark too fast can cause grain, an ugly mish-mash of uneven pigment.
Grain shows up the worst when you move to a darker color and you will need to either go back a step and return to applying the lighter color, or try to lightly sand it out without messing up your basecoat. Sometimes both! So make sure you have good coverage and don’t go dark too soon, that’s the best way to avoid the hassle with grain.
First, I apply a layer of Light Sienna.
Already it looks totally different and much much better! It’s a little streaky but that’s okay, more often than not the sealer application will darken the color and tone that down. The cloak now has a soft golden look to it. After blowing off the excess, I apply my sealer.
Will you look at that! The picture above looks NOTHING like that green disaster we had a short time ago! Now I wait for the sealer to dry, approximately 20 minutes but this may vary depending on the weather and humidity in your area.
As mentioned previously, I don’t want grain so I don’t go too dark too fast. I apply a second layer of Light Sienna and seal.
Notice how this time we have a lot more green undertone than previous. As I said, pigments and pastels are tints and translucent so basic color theory will start to apply.
How do you know when to apply one coat, two coat, or more of a certain color? For the most part, that is just going to come with experience and seeing how the colors lay down in various situations.
In this case, I don’t want any more green at this light color. Because of my planned colors, I know I’m going to get more green as I go but right now, want to go darker before we go greener. Make sense?
Now, I apply the Natural Umber. WOW! Major green going on here! Lol! This is not only going dark, it’s going REALLY green. So I decide one layer is enough. I don’t want the cloak to be the same color of green as the scented Pine deoderizer hanging from the review mirror in somebody’s car.
So let’s jump straight to the black. Now in this case, we want to use the black for shadows only. If we cover the entire cloak, it will go way too dark. I start by applying the Natural Black – or at least trying to. Unfortunately, even with the Colour Shaper applicators, the color has no strength to it at all. It’s going to take me forever at this rate. So I pull out my Black 318. Remember I said this stuff was strong? Check this out:
Yeah, this was supposed to be a minimal application. I don’t think “minimal” is in the dictionary when it comes to this black oxide.
So I seal layer four and look what I have as a result. The cloak just swerved a hard right from green to brown. See, I told you these things can still surprise me.
Now here is the fun part. This is where I get to show you how to do what I said (and demonstrated) earlier what NOT to do! 😆
I am going to apply a lighter color on top of a dark color, specifically a light brown. The cloak is now going too dark. There’s just too much “muck”. Again, this isn’t an exact science so you are going to get color twists and curves that you have to learn how to handle. Again, experience is the best teacher to know if you can work through it or if you have to strip it and start over. Always do you best to work through it, over it, sideways…something! Leave stripping as a last resort.
Experience also teaches you how various colors and types of pigments (this includes pastels too) will react. I mentioned the Black 318 is one of the strongest oxide pigments I have. Well, I have another oxide pigment that is strong, has great coverage and can almost handle anything thrown at it. It comes in a strong second to the Black 318. It is Titanium White.
The only problem, Titanium White has a very, very strong blue undertone. I’ve had it turn my stuff purple more times than I care to count! So I’ve learned to offset this with basic color theory and adding a color to the mix to help neutralize that blue undertone. In this case it is Light Yellow Ochre. The mix turns into a buff color and I apply a layer.
As before with the green, you see I have a very stark contrast between the light color and my original green/black. But I haven’t sealed yet and that is the key.
Upon application of the sealer, the light color does as before it nearly disappears completely. But if you look closely you can see where the light tan stuck and while it is still subtle, it stuck with a lot more strength than our first attempt.
It’s all about learning what specific types of oxides and ochers, as well as colors, can do.
Layer six, seven, and eight
I stay with this buff color for these next three layers. I need to mention these are specifically applied with the Colour Shapers and each layer sealed. What a difference in that photo above, huh? 🙂 And although I’m keeping my layers and sealer thin, we still don’t want to apply too many. So here is where I call the inside of the cloak done. Check out this last photograph!
The back of the cloak – leather effect
Above we achieved a nice light color with dark shadows. To me, the inside of the cloak looks like Oil Skin. But I would like to show you some quick and easy steps to create a true leather effect. Our first layer of color is as before Light Sienna and seal. For the second layer, this time I go ahead and go slightly darker – not much, just a little and apply a soft red color with a hint of orange called Rose Earth and I seal that as well.
Third and fourth layers
This is another new color called Cypress Umber Warm. Umbers have a tendency to posses a strong cool cast, basically blues and greens. This one has a warmer cast to it and I wanted to see how it would work. After sealing I immediately moved to the Black 318 but using my Colour Shapers I was very cautious to only apply it to the deepest recesses.
And wow – instant leather! And this is only four layers folks!
So what do I do after the sealer dries? I go and break my own rules again. At this rate, you’re not going to take me seriously! Lol! The Colour Shaders have a tip called a Cup Chisel. I used this and returned to my second layer color, Rose Earth. This time I applied it ONLY to the highest points on the folds of the cloak. The Cup Chisel works perfectly for this shape. And once again I sealed.
Again repeating the Rose Earth highlights with the Cup Chisel and sealing.
The insanity strikes again. Instead of going lighter on the high points of the cloak, this time I went redder. I used Colonial Red pigment and it is red without having a lot of orange but it’s not BRIGHT RED either.
I got interesting results so after I sealed I took a series of pictures. The only editing I did was to crop, resize and put them into a panel. The changes you see are only angle of camera and lightly. They are very small adjustments but you can see the effect this achieved.
Each panel appears to be different stages of pigment application but they are not. This is one application and the only thing changing is the position of the figure and the angle I’m holding the camera.
My friends, in my humble opinion, that is leather.
All of this created with dry pigments and “painting”.
A few words about metallics
Now this helm I did entirely with metallics and sealed with Dull Cote. I have different colors of silver metallics, just like we have different colors of silver paint. I used them for highlights and shadows just as if they were paint.
I do need to mention metallic pigments are an entirely different critter from regular pigments. They are NOT translucent and you need to use a black base coat with them, unlike the white of the regular pigments. Black allows them to pop. If you use white or a light colored base, they go kinda soft pastel colors rather than having the zing they normally do.
And here is a photo of the miniature we were painting. (Still very much a WIP)
I hope you’ve enjoyed this article and found it informative. Please comment if you have any questions! I am happy to help however I can.
Recent news about return of Confrontation miniatures under the new label of Legacy Miniatures reminded me about the tutorial I wrote about painting steeds for drune raiders. Even if it’s nothing new, you may still find it useful if you are looking for ideas how to paint chaos demons or steeds – this method of painting skin may inspire you to do something interesting.
As you can see the model I used was a Drune Raider from Confrontation, but the way I wanted to paint his steed was supposed to make it look demonic and unnatural. I feel that this skinned look with well defined muscles can be perfect for painting Chaos creatures.
When I am painting I often forget to take photos in the meantime, so I didn’t make a full step-by-step documentation.
That this skinned look with well defined muscles can be perfect for painting Chaos creatures.
I still hope that what I prepared gives some impression of how I created the effect that may be inspirations for those of you who wonder how to paint chaos models and their skin.
On the very beginning let me explain that the primer was not white. 😀 Don’t tune your display screens. 😉 It’s the grey spray from Maimeri Idea Spray (in my own palette of colors I would call it ‘ash-colored’).
I started painting with thinning VMC 960 “Violet” heavily.
Remembering about shapes of muscles I applied glazes with a brush. This way I became familiar with the shapes of this model and started creating the next moves.
The next color I used was transparent red-brown – VMC 828 “Woodgrain”.
I used it to define the horse’s muscles more boldly… First I outlined the sinews, and then I added direction to them.
To bind the colors and reduce the contrast, I added glazes in both colors where ever I painted sinews. Don’t try to achieve such an effect in one layer – it was creating by applying more than one layer of paint. The more layers the more saturated your colors will be.
The next step was applying shadows, which made me use black color. I used ink at this stage, because it adds no texture and allows me to manipulate in recesses and build up protruding muscles… With thin lines I painted transitions from light to shadow on the sinews without losing saturation of colors.
I glazed it with Transparent Blue because Vallejo Black color is not black enough for my concept of such sinister moods
Black looked a bit vulgar on the miniature, so I made it a bit milder by adding some violet and red-brown glazes on the borders of colors.
When I was thinking about the model, I wanted something to tone down the warmth of red colors and I decided to add some green. The drune’s tunic seemed to be a good place for this. To bind the colors of the rider and the horse together, I had to add some green to the whole palette, and so I decided about the area around the eyes, and – omitting the neck – head toward highlights of the lower parts. A color less saturated than reds an violets was supposed to imitate the effect of partial shading. But I found that adding VMC 920 “German Uniform” green made the horse look matt and made it bland and nondescript… and so I found another color 😀
“And in the darkness bind them…”
To bind the green with other colors on the horse I used VMC 938 “Transparent Blue” (as the name suggests it’s a transparent blue paint ;)). It’s most visible on the horse’s face, but you can see it also on the legs, where I used it to cover the green – not only on the edges (as it was done in the upper parts) but also glazed the whole green surfaces with it…
The subject is nearly completely covered now 🙂 To make it more complete I can add that I used VMC 907 “Pale Greyblue” (which is an equivalent of the primer I used) on some parts to highlight the top of sinews, and I covered the deepest shadows with black paint. The dullness of the paint made the black even deeper, and I glazed it with “Transparent Blue” because Vallejo Black color is not black enough for my concept of such sinister moods. 😉
Now you know how to paint Chaos creatures!
If you reached this part of the tutorial, you have enough patience for painting with glazes 😀 I hope you will share your own ideas and methods of painting evil and sinister creatures in comments below.
